| Cikkszám | UG-2864KSYMG01 |
| Márka | WiseChip |
| Méret | 1.54 |
| Alkalmazás | IA |
| Felbontás | 128×64 |
| Fogalmazás | OLED |
| Fényerősség | 150 |
| CR | 10000:1 |
| Színek | Mono(Yellow) |
| Háttérvilágítás | self |
| Felület | CPU/SPI/I²C |
| panel márka | WiseChip |
| panel modell | UG-2864KSYMG01 |
| panel típusa | PM-OLED , OLED |
| panel mérete | 1.54 inch |
| felbontás | 128×64 |
| aktív terület | 35.052×17.516 mm |
| vázlat | 42.04×27.22 mm |
| felület | |
| Fényerősség | 150 cd/m² (Typ.) |
| kontraszt arány | 10000 : 1 (Typ.) |
| kijelző színei | Mono(Yellow) |
| látószög | |
| driver ic | Built-in SSD1309 |
| jel interfész | 8-bit 6800/8080 parallel, 4-wire SPI, I²C |
| rohs: | |
| Alkalmazás | IA |
